DurabilityDurability

Durability

High-quality materials and a proven product.

Unlimited customizationUnlimited customization

Unlimited customization

Wide range of standard colors and numerous options.

Extensive motor rangeExtensive motor range

Extensive motor range

Available in 380V or 220V with various control and disengagement systems.

Our models

  • Normal lift

  • High lift

  • Vertical lift

  • Low headroom

Technical Information

    • Standard opening dimensions*: DLW7000 x DLH7000 mm.
    • Various track types: Standard, high lift, vertical, or low headroom.
    • Track angle: 0° to 40°.
    • Curtain made of “sandwich” panels, steel sheet on both sides, injected with CFC-free “PIR” polyurethane foam for excellent insulation.
    • Foam fire classification: B s2 d0.
    • Panel thickness: 42 mm.
    • Thermal resistance: U = 1.2 W/m²·K for a DLW3000 x DLH3000 door.
    • Sound insulation: 24 dB.
    • Stucco grooved finish on both sides (groove spacing: 100 mm).
    • Panel height: 610 mm.
    • Standard interior finish: White.
    • Exterior finish: Standard RAL or custom RAL (optional).
    • Side and intermediate hinges: Galvanized steel.
    • Curtain balance: Galvanized and coated torsion springs (20,000 cycles)
    • Rollers: Nylon with galvanized steel shaft and bearing.
    • Stainless steel hardware and tracks available as an option.
    • Full perimeter sealing with lip seals.
    • Bolted galvanized steel guide tracks with spreader bar (up to 7000 mm wide).
    • Types of operation: Manual, chain hoist or motorized.
    • GfA motors: 220V single-phase or 380V three-phase with chain hoist emergency operation (standard) or cord release (optional).
    • Control box: GfA TS971, wall-mounted with electronic limits switch.
    • Operating modes: Dead-man, impulse, or fully automatic (optional).
    • Safety system: Light curtains (depending on configuration).
    • Many options available: Glazed sections, windows, locks, etc.
    • Pedestrian passdoor: Optional integrated wicket door available.
    • Spring break and adjustable cable safety devices (depending on configuration).
    • CE certified product according to standard NF EN 13241-1.
    • *For other dimensions, please contact us.
